Products Introduction
This exterior cladding panel is developed for projects that require a balance between appearance, durability, and installation efficiency.
Using a composite structure that blends wood fibers with polymer materials, the panel keeps a natural surface look while improving resistance to moisture, sunlight, and long-term outdoor exposure.
The clip-based fixing method simplifies the installation process and helps achieve a clean and uniform finish.
Product Parameters
|
Technical Specifications |
|
|
Thickness |
8mm |
|
Size |
1220 x 2440mm (Custom options available) |
|
Material Composition |
WPC Composite |
|
Surface |
UV-treated / decorative film / veneer finish |
|
Touch Feeling |
Natural Wood Warmth & Texture + Smooth, Solid, |
|
Color |
Fully Customizable |
|
Certifications |
CARB NAF / GREENGUARD Gold / UL 94 |
|
Installation |
Clip fixing / frame system / screw fixing / adhesive support |
|
Functional Properties |
|
| Water Resistance | Designed for outdoor use with very low water absorption, suitable for humid environments. |
| Mold Resistance | Helps reduce the possibility of mold growth during long-term use. |
| Chemical Resistance | Stable performance when exposed to mild acidic or alkaline conditions. |
| Dimensional Stability | Less expansion or contraction compared with traditional wood materials. |
| UV Protection | Surface treatment slows down color fading caused by sunlight. |
Features and Applications
Installation Structure
Clip-based fixing system allows panels to be installed without exposed screws.
The structure helps create a more uniform surface and simplifies installation.
Compared with traditional methods, labor time can be reduced.
Weather Adaptability
Suitable for outdoor environments with exposure to rain, sunlight, and temperature variation.
Maintains structural stability under normal climate conditions.
Panel Design
Interlocking structure improves alignment and installation efficiency.
Ventilation space behind panels helps reduce moisture accumulation.
Surface has basic impact resistance for daily use.
Material & Environmental Aspects
Made with a high percentage of recycled materials.
Does not require frequent surface treatment such as painting or sealing.
Can be recycled after long-term use.
Maintenance
No regular coating or sanding required.
Cleaning can be done using water or mild detergent.
Surface is designed to reduce dirt accumulation.
Application Areas
Residential Use
– Exterior wall decoration
– Balcony and terrace cladding
– Garden structures and privacy panels
Commercial Use
– Shopfront decoration
– Hotel and public building walls
– Office exterior and renovation projects
Production Details
Main Features
Installation System
The panel uses a concealed fixing method, allowing installation without exposed screws or nails.
It can be assembled with common tools, making the process simple and efficient.
Compared with traditional systems, installation time can be reduced.
Durability Performance
Designed for outdoor use, the material performs well under moisture, sunlight, and temperature changes.
The surface has basic resistance to impact and daily wear.
It also meets standard fire safety requirements for building materials.
Environmental Consideration
The product is manufactured using a large proportion of recycled materials.
It does not release harmful substances during use and can be recycled after its lifecycle.
Maintenance Requirements
No regular treatment such as painting or sealing is needed.
Cleaning can be done with water or mild detergent.
The surface is designed to reduce dirt accumulation during use.
Structural Design
The panel includes a connection structure that improves alignment during installation.
A ventilation gap behind the panel helps reduce moisture buildup.
It also contributes to stable performance over time.
Technical Specifications
|
Attribute |
Details |
|
Material Composition |
WPC composite material with a high proportion of recycled content (approx. 85%) |
|
Panel Dimensions |
Width: 200mm / 300mm Thickness: 16mm / 20mm Length: 2400mm / 3600mm |
|
Coverage per Panel |
200mm panel: approx. 0.48㎡ per piece 300mm panel: approx. 0.72㎡ per piece |
|
Weight |
Hollow structure: around 3.2kg/㎡ Solid structure: around 5.5kg/㎡ |
|
Fire Rating |
Complies with Class A standard based on ASTM E84 |
|
Water Absorption |
Water absorption rate remains below 0.3% |
|
Warranty |
Up to 25 years coverage under normal use, including structural integrity and color performance |
Applications
Suitable for residential and commercial use, such as exterior walls, balconies, fences, shops, hotels, and offices.
Also applicable for special areas like poolside and outdoor structures.
Why Choose Our System?
Over 10 years of production experience with stable supply.
In-house manufacturing ensures consistent quality.
Custom sizes and colors are available.
Products meet common international standards.
Installation Guidelines
Install panels on a leveled substructure.
Basic steps:
1.Fix clips onto the frame
2.Insert panels into clips
3.Leave expansion gaps at edges
4.Finish edges with trims
Typical installation efficiency depends on project conditions.
Support & Service
Installation guidance and basic technical support are available.
Samples can be provided for testing before bulk orders.
Product Qualification
FAQ
Q: How is the panel installed?
A: Panels are fixed using clips attached to a subframe. They are then locked into place without visible fasteners.
Q: Is professional installation required?
A: ANot necessary for simple projects, but recommended for large-scale applications.
Q: Can it be used outdoors?
A: Yes, it is designed for exterior use under normal environmental conditions.
Q: How to maintain it?
A: Clean with water or mild detergent. No special maintenance required.
Q: Is it environmentally friendly?
A: It contains recycled materials and can be reused after its service life.
